Audio-Technica AT-LPW40WN Belt-Drive Turntable

3 Reviews
Original price $699.00 - Original price $699.00
Original price $699.00
$699.00
$699.00 - $699.00
Current price $699.00

Audio-Technica AT-LPW40WN Belt-Drive Turntable

Need bluetooth? Add an optional adapter for an additional $89 to create a bluetooth turntable.

Limited stock available.

Fully Manual Belt-Drive Turntable

The AT-LPW40WN is a fully manual, belt-drive turntable designed to give you optimal high-fidelity audio reproduction from vinyl. It features an aesthetically pleasing anti-resonance MDF (medium density fiberboard) plinth with simulated walnut wood veneer to limit low-frequency acoustical feedback and a sensor-monitored motor to ensure accurate platter rotation speeds at 33-1/3 and 45 RPM.

The turntable includes a straight carbon-fiber tonearm with adjustable tracking force and an AT-HS4 universal ½”-mount headshell with an AT-VM95E Dual Moving Magnet phono cartridge. Audio-Technica has been a leader in phono cartridge design for more than 50 years, and that expertise shows in the versatile, high-performance AT-VM95E cartridge, which comes with a 0.3 x 0.7 mil elliptical stylus, but is also compatible with any VM95 Series replacement stylus, offering a wide choice of options for every budget and application.

The AT-LPW40WN is equipped with a built-in selectable phono preamp and a detachable dual RCA output cable to enable direct connection to components with or without a dedicated phono input.

Features

  • Fully manual, belt-drive operation with two speeds: 33-1/3 and 45 RPM
  • Motor features a speed-sensor system to maintain accurate platter rotation speed
  • Fully manual operation
  • Adjustable dynamic anti-skate control
  • Professional anti-resonance, die-cast aluminium platter with rubber mat
  • AT-HS4 universal ½"-mount headshell and AT-VM95E Dual Moving Magnet phono cartridge with 0.3 x 0.7 mil elliptical stylus
  • AT-VM95E cartridge is compatible with any VM95 Series replacement stylus, offering a wide choice of options for every budget and application
  • Straight carbon-fiber tonearm with hydraulically damped lift control and lockable rest
  • Anti-resonance MDF (medium density fiberboard) plinth with walnut simulated wood veneer
  • Built-in switchable phono pre-amplifier for phono or line-level output
  • AC adapter handles AC/DC conversion outside of the chassis, reducing noise in the signal chain
  • Includes dual RCA (male) to dual RCA (male) stereo cable, 45 RPM adapter, rubber mat, and removable hinged dust cover.
audio-technica at-lpw40wn belt-drive turntable melbourne hi fi
Specifications
Type

2-speed, fully manual operation

Motor

DC servo motor w/speed stability control

Drive Method

Belt drive

Speeds

33-1/3 RPM, 45 RPM

Turntable Platter

Die-cast aluminium

Wow and Flutter

0.15% (WTD) @ 3 kHz (JIS)

Signal-to-Noise Ratio

>60dB

Output Level

Pre-amp “PHONO”: 4 mV nominal at 1 kHz, 5 cm/sec
Pre-amp “LINE”: 200 mV nominal at 1 kHz, 5 cm/sec

Phono Pre-Amp Gain

35 dB nominal, RIAA equalized

Power Supply Requirements

100-240V AC, 60 Hz

Power Consumption

1 W

Dimensions

420.0mm W x 340.0mm D x 116.9mm H

Weight

4.7kg

Accessories Included

AT-VM95E phono cartridge; AT-HS4 headshell; dual RCA (male) to dual RCA (male) cable with ground wire; counterweight; rubber mat; dust cover; 45 RPM adapter

Tonearm type

Balanced straight tonearm with detachable headshell

Effective arm length

223.6mm

Overhang

18.6mm

Tracking error angle

<2 degrees

Applicable cartridge weight

12-17g

Anti-skating range

0-3g

Replacement Stylus

AT-VMN95E
