The Denon PMA-3000NE delivers 160W per channel at 4 ohms and 80W per channel at 8 ohms, driving even the most demanding speaker to deliver superior sound in any scenario. Designed and manufactured at Denon facilities in Shirakawa, Japan.

• 2 channels
• 160 watts per channel
• MM/MC phono stage
• Ultra AL32 Processing
• Optical, coaxial, and USB digital connections

Audio excellence, redefined

With an advanced push-pull amplifier, sophisticated digital processing, and a robust phono stage, the PMA-3000NE delivers all of your favorite music with clarity and precision.

Faithful to any sound source

Drives even the most demanding speakers

A push-pull amplifier, delivering 80W/channel into 8 ohms and 160W/channel into 4 ohms, effortlessly accommodates a range of speaker types and impedances.

Seamlessly integrate high-resolution digital audio

Digital connections, including optical, coaxial, and USB-B, support up to 384kHz/32- bit. Ultra AL32 Processing waveform interpolation produces smooth, high-resolution sound.

Unlock your vinyl collection's full potential

The PMA-3000NE's phono stage supports both MM and MC cartridges, for the most faithful sonic reproduction regardless of cartridge type.

Fidelity, form, and function

Advanced amplifier design

The PMA-3000NE delivers 80W/channel into 8 ohms and 160W/channel into 4 ohms. Its UHC-MOS single push-pull circuit and differential 2-stage amplifier drive demanding speakers with exceptional clarity and linearity.

Ultra AL32 Processing

Denon's Ultra AL32 Processing uses interpolation algorithms to produce highresolution output. Supporting input signals up to 384kHz/24-bit, it upsamples for smoother waveforms and improved sound reproduction.

High-performance MM/MC phono stage

The PMA-3000NE's phono stage supports both MM and MC cartridges for truest vinyl reproduction in any setup. A high-gain design and “simple and straight” circuitry minimize distortion for pure, detailed sound.

Digital audio inputs

The PMA-3000NE’s versatile digital connections, including optical, coaxial, and USB Type B, support up to 384kHz/32-bit and 11.2MHz DSD audio.

Pure analog made

Pure Analog mode bypasses digital circuitry for a pure, all-analog sound. A Source Direct function bypasses the tone controls so that the signal path is as short and clean as possible, for enhanced clarity.

Specifications

• Rated Output Power: 80W + 80W (8 ohm,20 Hz-20 kHz,THD 0.07%), 160W + 160W (4 ohm, 1 kHz, THD 0.7%)
• Total Harmonic distortion: 0.01 % (Rated output: –3 dB), 8 ohm/ohms, 1 kHz
• Input Sensitivity: Phono inputMM: 2.5 mV / 47 kohm, MC: 200 μV / 100 ohm
• Input Sensitivity:CD/LINE/RECORDER: 135 mV / 19 kohm
• Input Sensitivity: Power Amp input: 0.9V / 47 kohm (EXT. PRE)
• Signal to Noise Ratio: PHONO (MM): 89 dB, PHONO (MC): 74 dB, CD: 107 dB
• Power Consumption: 400W
• Power Consumption at Standby: 0.2W TV autoplay off, 0.4W TV autoplay on

• Unit (W × H × D): 434 × 182 × 443 mm
• Net Weight: 24.6 kg / 54.2 lbs
• Panel Cover: Silver, Black

• Power Amplifier Circuit: New UHC-MOS, Single Push Pull (7)
• Preamplifier Circuit: Variable Gain Preamplifier (OP AMP)
• Bass / Treble / Mid / Balance ControlYes / Yes / No / Yes
• Source Direct: Yes
• Analog Amp Mode: Yes (button on front panel)
• DAC Circuit: ES9018K2M × 4
• Digital Processing: Ultra AL32 Processing
• DAC Master Clock Design: Yes
• Asyncronous mode (for USB-B input):Yes

• Phono Input: Yes (MM / MC), *default = MM
• Analog Input (include Phono) / REC Out (RCA): 4/1 (Gold Plated) (Brass Machining type for all CD/PHONO/AUX/RECORDER)
• Optical input / output(Maximum Support): 3 / 0 (192 kHz/24-bit)
• Coaxial input / output (Maximum Support): 1 / 0 (192 kHz/24-bit)
• Speaker Terminal: AVR-A1H type Gold Plated w/Cover
• Headphone Output1 (Turns off the speaker automatically when headphone is inserted)
• Remote Control: Yes
• Remote Control Bus Terminal: Yes (mini)
• Wi-Fi: No
• HEOS: No
• USB B (USB DAC): 1 (Rear)
• PCM Sample Rate / Resolution: ~384 kHz/32-bit
• DSD Audio Streaming: ~11.2MHz
